產品中心 > PA RL600 sst gun 高壓清洗機水槍spray沖洗設備pressure washer噴槍
PA RL600 sst gun 高壓清洗機水槍spray沖洗設備pressure washer噴槍特點
額定壓力 600 巴 - 60 MPa - 8700 psi
允許壓力 660 巴 - 66 MPa - 9500 psi
額定流量 60 升/分鐘 - 15，8 美制加侖/分鐘
額定溫度 100 °C - 210 °F
防護等級 IPX3
防護等級 III
肩托 30.5060.00
附加說明
入口旋轉接頭，編號 30.5840.00
PA RL600 sst spraygun 清洗機高壓水槍描述
噴槍適用于額定壓力高達 600 bar – 60 MPa / 8000 PSI 的泵。完全由不銹鋼制成。
還提供高抗性干簧開關，防護等級IPX3，防護等級III。由扳機的運動進行磁控。
P/N Inlet Outlet Weight Package Quantity
30.5800.00 3/8 Bsp F 3/8 Bsp F 991 gr - 34,95 oz 1
30.5820.00 3/8 Bsp F 3/8 Bsp F 1039 gr - 36,65 oz 1
Magnetic reed switch I= 0,5 A - V=48V AC/DC - P = 10 VA - 2 m cable
Common Features
Rated Pressure 600 bar - 60 MPa - 8700 psi
Permissible Pressure 660 bar - 66 MPa - 9500 psi
Rated Flow Rate 60 l/min - 15,8 USGpm
Rated Temperature 100 °C - 210 °F
Protection Degree IPX3
Protection Class III
Shoulder rest 30.5060.00
Additional Notes
Inlet swivel, n° 30.5840.00
Description
Gun suitable for use with pumps up to 600 bar – 60 MPa / 8000 PSI rated pressure. Entirely made of stainless steel.
Also available with highly resistant Reed switch, protection degree IPX3, protection class III. Magnetically controlled by the movement of the trigger.
